How to program your Somfy Connexoon Hub

1 Get organised

Make sure you've activated your Hub and downloaded and logged in to the mobile app (see end user quick install guide). When you log in for the first time the app will ask you to confirm your latitude and longitude.

Have your Somfy remote to hand. If you haven't set up your Somfy remote yet, do this first.

2 Start adding your blind or curtain

In the app tap the menu icon in the top left corner and select Configuration from the menu options. Press the add button on the Configuration screen.

If your blinds or curtains were manually added during install, head straight to I need some extra help at the bottom of this page.

3 Choose your product type

In the app choose RTS devices and tap OK at the bottom.

4 Choose your device type

In the app tap the device you're adding:

For roller blinds tap Interior Roller Blind.

For left or right stack curtains tap 1 Way Curtain.

For centre opening curtains tap 2 Ways Curtain.

5 Test your blind or curtain

Grab your remote control.

For 1 channel remotes press up or down on your remote control to check the blind or curtain is working.

For 5 channel remotes pick the right channel on your remote for the blind or curtain you're adding. Press up or down on your remote control to check the right blind or curtain is working.

6 Add your blind or curtain (part A)

With a paperclip or pin hold down the programming button on the back of your remote control for approx. 3 seconds, until your blind or curtain jogs.

7 Add your blind or curtain (part B)

In the app tap OK and then tap add. Make sure you tap add within 2 minutes. Your blind or curtain will jog again. Then tap add a second time.

8 Confirm your blind or curtain is added

In the app tap Test to check that the product has been added. Your blind or curtains will move (or flash) for 5 seconds. Tap Stop then tap OK to continue. If you didn't notice your blind or curtain move or flash just keep going for now and you can test it once you've finished.

If your blind or curtain hasn't been added, you can tap restart to try again or abort if the step won't work after a few tries. Refer to your motorised roller blinds or curtains manual or call us and we'll help you set up.

9 Give your blind or curtain a name

In the app type the name of your blind in the grey box, e.g living room blind 1 and tap return on your phone's keypad. Tap OK at the bottom of your screen to finish adding your blind or curtain.

10 Finish adding your blind or curtain

You're all done! Your blind or curtain will now show at the bottom of your app's home screen and you can scroll horizontally if you have multiple blinds or curtains.

Use the up and down buttons to control your blind and the my button to stop your blind moving. If your blind doesn't move when you tap the app buttons see I need some extra help at the bottom of this page.

If you have multiple blinds and curtains, repeat steps 1 - 10 for all your motorised products, one by one. You can control all your blinds or curtains with one tap by setting up scenarios and ambiances (see Privacy, weather and security tab of this guide). You can also set up scheduling (see Scheduling tab of this guide).

1 Getting started

Before you start set your geolocation and your timezone in the Settings and Advanced settings sections of your app menu.

Make sure you've added all your blinds and curtains to your Hub, using the Set up your Hub tab in this guide.

2 How scenarios work

Use scenarios to set up home, away, sun protection and privacy modes. You can find scenarios in the tab with the Star icon located right under the menu. Tapping the grey pencil icons lets you edit a scenario.

Within a scenario you can: choose the blinds or curtains you want to control and choose what you want them to do (e.g. open); choose if you want your timed programs to be on or off when you're using the scenario; choose if you want to run a simulated presence.

3 How ambiances work

Use ambiances to set up extra modes to suit your lifestyle e.g. day time movies. You can find ambiances in the middle tab located under the menu. Tapping the add symbol (+) lets you add an ambiance and tapping the grey pencil icon lets you edit an ambiance.

With an ambiance you can: add a photo of your room or icon to your ambiance so you can easily recognise it; choose the blinds or curtains you want to control and choose what you want them to do (e.g. open); name your ambiance by typing in the grey box.

1 Getting started

Before you start set your timezone in the Advanced Settings section of your app menu.

Make sure you've added all your blinds and curtains, using the Set up your Hub tab in this guide.

2 How timed programming works

You can find timed programming in the tab with the clock icon located under the menu. Tapping the slider button lets you turn programming on (green) and off and tapping the grey pencil icons lets you edit programs.

With timed programming you can: add a new program; name your program; choose a specific time or select sunrise or sunset; adjust if your blinds or curtains open or close before, exactly at or after sunrise and sunset; choose the days of the week; choose the blinds and curtains you want to schedule and what you want them to do (e.g. open); activate and deactivate programs when you're viewing your program list (orange box to the left of the program name means activated).

Remember to set up your sunrise and sunset times as two separate, timed programs.
